TECHNICAL SPECIFICATIONS

Length: Mechanical

Width: Mechanical

Height: Mechanical

Heating Power: 3.6 kw

Height Adjustment: Redactor (Mechanical)

Opener Palette: Motor 0.37 kw + Inventor

Anti-Static Electricity: Available

Edge Control: Available

Drives: Servo Motor 1.2 kw + Inventor

Operator Panel: 7 Inc

Control System: PLC

Tension Control: Electronic

Folding Head Size: Optional (Min 23 cm - Max 40 cm)

Packing Speed: 25 - 55 Packet/ Minutes

Printing Unit: Optional (Min 1 - Max 8) / Twin Packet

Machine Weight: 3300 kg

Air: 0.5 - 0.8 mpa

Power Supply: 380 V - 50 Hz

Motor Power: 1.5 kw
